Filter by

Type

Brand

Jib length

Max. Load at Radius

Jib Radius & Lift Capacity

Jib length:50m

Max. Load at Radius:25.9m x 4.0t

Jib Radius & Lift Capacity:27.3m x 3.79t | 35m x 2.92t | 40m x 2.54t | 45m x 2.24t | 50m x 2.0t

Jib length:45m

Max. Load at Radius:17.3m x 8.0t

Jib Radius & Lift Capacity:27.3m x 4.97t | 35m x 3.81t | 40m x 3.3t | 45m x 2.9t

Jib length:40m

Max. Load at Radius:19.3m x 8.0t

Jib Radius & Lift Capacity:27.3m x 5.56t | 35m x 4.27t | 40m x 3.7t

Jib length:35m

Max. Load at Radius:20.7m x 8.0t

Jib Radius & Lift Capacity:27.3m x 5.98t | 35m x 4.6t

Minimum out of service radius: **10m (45-50m) | 12m (27.3-35-40m)**
Power requirement – mains: **100 kVA**
Power requirement – generator: **200 kVA**
Running current: **130 Amps**
Surge on start up: **145 Amps**

Jib length

Max. Load at Radius

Jib Radius & Lift Capacity

Jib length:50m

Max. Load at Radius:21.5m x 6.0t

Jib Radius & Lift Capacity:27.3m x 6.0t | 35m x 3.57t | 40m x 3.08t | 45 x 2.7t | 50m x 2.4t

Jib length:45m

Max. Load at Radius:23.7m x 6.0t

Jib Radius & Lift Capacity:27.3m x 6.0t | 35m x 3.95t | 40m x 3.42t | 45m x 3.0t

Jib length:40m

Max. Load at Radius:26.1m x 6.0t

Jib Radius & Lift Capacity:27.3m x 6.0t | 35m x 4.39t | 40m x 3.8t

Jib length:35m

Max. Load at Radius:27.3m x 6.0t

Jib Radius & Lift Capacity:27.3m x 6.0t | 35m x 4.6t

Minimum out of service radius: **10 (45-50m) | 12m (27.3-30-35m)**
Power requirement – mains: **60 kVA**
Power requirement – generator: **120 kVA**
Running current: **80 Amps**
Surge on start up: **100 Amps**

Jib length

Max. Load at Radius

Jib Radius & Lift Capacity

Jib length:45m

Max. Load at Radius:13.3m x 6.0t

Jib Radius & Lift Capacity:20m x 3.9t | 30m x 2.52t | 35m x 2.13t | 40m x 1.83t | 45m x 1.6t

Jib length:40m

Max. Load at Radius:17.6m x 6.0t

Jib Radius & Lift Capacity:20m x 5.22t | 30m x 3.42t | 35m x 2.89t | 40m x 2.5m

Jib length:35m

Max. Load at Radius:19.9m x 6.0t

Jib Radius & Lift Capacity:20m x 5.94t | 30m x 3.91t | 35m x 3.3t

Jib length:30m

Max. Load at Radius:21.4m x 6.0t

Jib Radius & Lift Capacity:20m x 6.0t | 30m x 4.2t

Minimum out of service radius: **9.6m (40-45m jib) | 10.9m (20-30-35m jib)**
Power requirement – mains: **60 kVA**
Power requirement – generator: **120 kVA**
Running current: **80 Amps**
Surge on start up: **100 Amps**

Jib length

Max. Load at Radius

Jib Radius & Lift Capacity

Jib length:35

Max. Load at Radius:17.7m x 4.0t

Jib Radius & Lift Capacity:15m x 4.0t | 20m x 3.55t | 25m x 2.83t | 30m x 2.35t | 35m x 2.ot

Jib length:30m

Max. Load at Radius:18.9m x 4.0t

Jib Radius & Lift Capacity:15m x 4.0t | 20m x 3.77t | 25m x 3.01t | 30m x 2.5t

Jib length:25m

Max. Load at Radius:20.6 x 4.0t

Jib Radius & Lift Capacity:15m x 4.0t | 20m x 4.0t | 25m x 3.3t

Minimum out of service radius: **4m**
Power requirement – mains: **45 kVA**
Power requirement – generator: **90 kVA**
Running current: **54 Amps**
Surge on start up: **65 Amps**

Jib length

Max. Load at Radius

Jib Radius & Lift Capacity

Jib length:40m

Max. Load at Radius:15.9m x 4t

Jib Radius & Lift Capacity:20m x 3.15t | 25m x 2.49t | 30m x 2.05t | 35m x 1.74t | 40m x 1.5t

Jib length:35m

Max. Load at Radius:18.2m x 4t

Jib Radius & Lift Capacity:20m x 3.62t | 25m x 2.86t | 30m x 2.36t | 35m x 2.0t

Jib length:30m

Max. Load at Radius:19.9m x 4t

Jib Radius & Lift Capacity:20m x 3.98t | 25m x 3.15t | 30m x 2.6t

Jib length:25m

Max. Load at Radius:21.4 x 4t

Jib Radius & Lift Capacity:20m x 4.0t | 25m x 3.4t

Minimum out of service radius: **10m (35-40m jib) | 9m (25-30m jib)**
Power requirement – mains: **45 kVA**
Power requirement – generator: **90 kVA**
Running current: **54 Amps**
Surge on start up: **65 Amps**

Jib length

Max. Load at Radius

Jib Radius & Lift Capacity

Jib length:50m

Max. Load at Radius:26.6m x 5.0t

Jib Radius & Lift Capacity:15m x 5t | 20m x 5t | 30m x 4.61t | 40m x 2.85t | 50m x 1.8t

Jib length:40m

Max. Load at Radius:17.7m x 10.0t

Jib Radius & Lift Capacity:15m x 10t | 20m x 8.63t | 30m x 5.01t | 40m x 3.2t

Jib length:30m

Max. Load at Radius:18.1m x 10.0t

Jib Radius & Lift Capacity:15m x 10t | 20m x 9.02t | 30m x 5.4t

Minimum out of service radius: **18.7m**
Power requirement – mains: **70 kVA**
Power requirement – generator: **150 kVA**
Running current: **160 Amps Amps**
Surge on start up: **177 Amps Amps**
